Hardware Parameter
Dimension
205mm×140mm×37mm(L×W×H)
Net weight
0.34Kg
Operating condition
Operating temp: -10 ~ +55°C
Operating humidity: 5 ~ 95% (non-condensed)
Storing condition
Storing temp: -40 ~ +70°C
Storing humidity: 5 ~ 95% (non-condensed)
Power adapter
DC 12V, 1/1.5A, external AC-DC power adaptor
Power supply
≤10W
Interfaces
1GE(WAN/LAN1)+3GE(LAN)+Wi-Fi 5+USB 3.0
Indicators
PWR, PON, LOS, WAN, ETH1~ETH4, 2.4Ghz Wi-Fi, 5Ghz Wi-Fi, WPS, USB
○ Interface parameter
PON interface
l 1XPON port(EPON PX20+ and GPON Class B+)
l SC single mode, SC/UPC connector
l TX optical power: 0~+4dBm
l RX sensitivity: -27dBm
l Overload optical power: -3dBm(EPON) or -8dBm (GPON)
l Transmission distance: 20KM
l Wavelength: TX 1310nm, RX1490nm
Wi-Fi interface
l Compliant with IEEE802.11b/g/n/ac
l 2.4GHz Operating frequency: 2.4000-2.4835GHz
l 5.0GHz Operating frequency: 5.150-5.825GHz
l Support MIMO, rate up to 1.167Gbps
l Wi-Fi: 2.4GHz( 2T2R ), 5.8GHz( 2T2R ), 5dBi antenna, support: multiple SSID
l TX power: 11n–22dBm/11ac–24dBm
LAN interface
4*GE, Auto-negotiation, RJ45 ports
USB interface
USB 3.0 for Shared Storage/Printer
○ Function Data
XPON mode
Dual mode , can access EPON/GPON OLTs(HUAWEI,ZTE,FiberHome, etc.)
Connect mdoe
Routing Mode
W-iFi
l IEEE802.11b/g/n/ac(TX power:17dBm/16dBm/15dBm)
l Wi-Fi Authentication : WEP/WAP-PSK(TKIP)/WAP2-PSK(AES)
Firewall
DDOS, Filtering Based on ACL/MAC/URL
Layer2
802.1D & 802.1ad bridge, 802.1p Cos,802.1Q VLAN
Layer3
IPv4/IPv6 , DHCP Client/Server , PPPoE , NAT , DMZ , DDNS
Multicast
IGMP v1/v2/v3 , IGMP snooping
Security
Flow & Storm control, Loop Detection
O&M
WEB/TELNET/OAM/OMCI, Support private OAM/OMCI protocol and Unified network management of VSOL OLT
